SF108 CD Inductor

型号	电感值	直流电阻	额定电流	测试频率	下载
Num	L	DCR	IDC	TEST FRAQ	Download
	( μH )	( mΩ )	( A )
	TYP	MAX	MAX
SF108-472M-R-S-LF	4700	8700	0.25	100KHz/0.25V	SF108-SERIES.PDF
SF108-602M-R-S-LF	6000	11300	0.2	100KHz/0.25V	SF108-SERIES.PDF
SF108-682M-R-S-LF	6800	13000	0.18	100KHz/0.25V	SF108-SERIES.PDF
SF108-802M-R-S-LF	8000	14800	0.15	100KHz/0.25V	SF108-SERIES.PDF

Package：800pcs/r

|   SF108 CD Inductor Size

|   SF108 CD Inductor Application

SF108 CD Inductor is widely used in consumer electronics, small household appliances, high-speed hair dryers, audio equipment, headphones, vacuum cleaners, power circuits, etc.
